KOMATSU PC20 Track Chain Assembly with Mid-Frequency Heat-Treatment Technology Self-Lubricated System and Precision Assembly Dimensions

KOMATSU PC20 Track Chain Assembly with Mid-Frequency Heat-Treatment Technology Self-Lubricated System and Precision Assembly Dimensions

Detalhes do produto:
Lugar de origem:	China (continente)
Marca:	YT
Número do modelo:	PC20
Condições de Pagamento e Envio:
Quantidade de ordem mínima:	1pcs
Preço:	negotiable
Detalhes da embalagem:	Exportar embalagem
Tempo de entrega:	7-30 dias
Termos de pagamento:	L/c, t/t
Habilidade da fonte:	10000 PCs/mês

contacto

Informação detalhada
Material:	aço 40Mn2 ou 35MnBH	Técnica:	Forjamento e tratamento térmico
Qualidade:	Tratamento térmico HRC 40-55	Termo de preço:	FOB/CFR/CIF/EXW
Cor:	amarelo ou preto	Tempo de garantia:	12 a 18 meses
Doença:	Novo	Peso:	Opcional
Destacar:	Mid-Frequency Heat-Treatment Technology Track Chain Assembly , Self-Lubricated System Track Link Group , Precision Assembly Dimensions Excavator Undercarriage Spare Parts

Descrição de produto

KOMATSU Excavator Undercarriage Spare Parts PC20 Track Chain Assembly

OEM Track Link Group With Mid-Frequency Heat-Treatment Technology

Track Link Features

Utilizing sophisticated machining centers, including horizontal and vertical CNC technology, we perform precision operations like cutting, boring, tapping, and grinding to guarantee component quality and accuracy. This ensures precise assembly dimensions while extending component lifespan and minimizing hourly production expenses.

Track links are manufactured from 35 MNB forged special steel, reinforced with advanced structure technology and heat treatment processes. This combination delivers maximum strength and abrasion resistance. The integrated self-lubricated system significantly enhances track chain bearing service life.

Main Dimensions of Installation

Suitable Model	P	A	B	C	E	F	H	K	L
EX30/EX35/PC20/PC30/PC35R	101.6	55	55	22	10.5	35	76	63	26
IHI30J	101.6	64	64	22	10.5	44	85	63	26
PC20	101.6	52	52	22	10.5	32	73	65	28
YC35	101.6	55	55	22	12.5	35	77	70	30
TM20	101.6	55	55	22	10.5	34	72	61	29.5
PC40-7/SK45	135	93.8	63.8	46	12.5	40.4	87.4	65	30
EX40/EX45	135	104	80	46	12.5	52	105	65	30
PC60-6/PC75/SK60	154	89	73	57	14.5	45	104	74	33.5
PC100-1/2/PC100-3/HD350	154	112.4	82.4	57	14.5	49.4	124.4	87	40
EX60-1/2/3/5	154	90	90	55	14.5	56	127	80	38

The models above are for reference only. We can supply additional products to meet your requirements. Please contact us with your specific needs.

Manufacturing Processes

Our Advantages

World-class quality components
Factory-direct pricing for cost efficiency
Flexible payment terms including T/T and L/C
Fast delivery within 30 days after contract confirmation
Comprehensive after-sale services including video technical support and 24/7 online assistance
